Compact high-output design delivers 128 dB peak via shared-magnet coaxial driver: 1.7-inch compression driver and 8-inch low-frequency driver.
Multipurpose versatility for deployment as main, monitor, fill, or delay; extend system bandwidth to 35 Hz by pairing with AMS115 subwoofer.
Consistent tonality and voicing with AM array modules and AMU utility loudspeakers — easily create entire systems and save substantial time during system configuration.
Proprietary Beamwidth Matching Waveguide ensures signature sound quality, aligning low and high beamwidth through crossover region to deliver excellent tonal consistency across the coverage area.
Multi-position enclosure with 110° × 60° coverage angle — easily swap horizontal and vertical coverage by simply rotating cabinet, no disassembly or tools required.
Lightweight 13 kg (29 lb) cabinet with large, ergonomic handle and 35 mm pole stand adaptor for easy transportation and setup.
Pair with Bose Professional PowerMatch amplifiers and ControlSpace DSP for best performance and loudspeaker protection.
Deploy easily in permanent or portable applications with optional U-bracket, suspension bracket, Pan-and-tilt bracket for RMU, or use the 6 integrated M10 inserts for custom suspension
Companion AMS115 multipurpose subwoofer also available — 15-inc.h transducer, low frequency down to 35 Hz, 130 dB peak output, 28 kg (63 lb) design with integrated M20 threaded pole mount and 12 M10 threaded inserts for suspension in permanent installations.
SPECS
Technical Specification COMPLIANCE
EN 54-24 Certified No
PHYSICAL
Colors
Black
Enclosure Material
Baltic birch plywood
Grille
Perforated steel, powder-coated finish
Ingress Protection
IP43 (front-of-house position only)
Suspension/Mounting
1 × 35 mm (1.4 in) pole cup, 4 × M8 threaded inserts, 6 × M10 threaded inserts
Product Dimensions (H×W×D)
12.5 in × 12.5 in × 10.5 in (318 mm × 318 mm × 268 mm)
