รุ่น EM ยังออกแบบให้มีมุมกระจายเสียงแนวตั้ง 75 องศา เหมาะอย่างยิ่งสำหรับห้องที่มีเพดานสูง เพื่อครอบคลุมเสียงได้ทั่วถึงทุกมุมห้อง
FEATURES
Combine DesignMax models to complete any design, big or small — 12 loudspeakers to mix and match, from 2-inch, low-profile models to 8-inch, high-SPL compression-driver loudspeakers and outdoor-rated options
Deliver rich lows and clear, intelligible highs with coaxial two-way drivers — no DSP or EQ required. For even better sound, use select Bose Professional DSPs and amplifiers to enable Bose Professional loudspeaker EQ and SmartBass processing, which expands performance and response at any listening level
Blend with any room design with elegant form factors, minimum-bezel grilles available in black or white, and removable logos
Reduce installation time with the patented QuickHold mounting system, which also reduces strain, hassle, and the chance of product damage
Install easily with industry-standard accessories — all models include Euroblock connectors; in-ceiling models include plenum-rated backcans, tile bridges, and front-access audio wiring that makes installation and troubleshooting easier
Deliver high SPL for demanding applications, including high-ceiling venues such as ballrooms, concourse, and convention centers
SPECS
Technical Specification COMPLIANCE
Safety Agency Ratings UL-1480A, S5591/ UL Listed, in compliance with UL2043 for plenum-space installation, NFPA70 & NFPA90-A, CE compliant
PHYSICAL
Frequency Range (-10 dB) 52 Hz – 20,000 Hz
Coverage, Horizontal 135° conical
Calculated Maximum SPL @ 1 m 113 dB
Nominal Impedance 8 Ω (transformer bypass)
Power Handling, long-term continuous 150 W
Power Handling, Peak 600 W
Recommended Signal Processing Not required, Bose Professional EQ voicing and SmartBass processing available
