Maintain consistent tonal quality with shared voicing across all FS models
Hear the best of both — music and voice — with transducers that offer clear voice reproduction and smooth response for background music
Customize systems with confidence using in-ceiling, surface-mount, and pendant-mount options, allowing for tailored mix-and-match installations. DesignMax subwoofers and larger models can expand your system design options even further
Blend with more room designs with updated enclosures — available in black and white — that pair modern aesthetics with practical features, including removable logos
Tackle site-specific challenges with the support of a full suite of accessories, designed to handle a wide range of applications and mounting options
Install with ease — all models feature Euroblock inputs and front-baffle input location on in-ceiling models
Support public safety — EN54-24 for Voice Alarm Systems for Fire Detection and Fire Alarm Systems for Buildings
SPECS
Technical Specification
COMPLIANCE
EN 54-24 Certified Yes
Safety Agency Ratings EN 54-24:2008 for Voice Alarm Systems; UL 1480(A); in compliance with UL 2043 for plenum-space installation; NFPA 70 & NFPA 72; CSA C22.1 Section 32
PHYSICAL
Colors Black (similar to RAL 9005), white (similar to RAL 9003)
Enclosure Material Engineered-plastics front baffle with integrated steel-formed backcan
Environmental Indoor only, suitable for use in plenum locations
Grille Perforated steel, powder-coated finish
Ceiling Cutout 6.3 in (160 mm)
Logo Rotatable, removable
Suspension/Mounting (2) mounting arms, (1) safety cable attachment point
Operating Temperature Range 0 °C to 50 °C (32 °F to 122 °F)
Product Dimensions (H×W×D) 7.2 in × 5.2 in (182 mm × 132 mm), loudspeaker diameter × depth / 5.0 in × 4.9 in (127 × 125 mm), backcan diameter × depth
Net Weight 3.6 lb (1.6 kg), loudspeaker with grille (single)
